JET CHISEL

A jet chisel (also called needle scaler) is a pneumatic tool made up of multiple thin steel rods (“needles”) that rapidly move back and forth when connected to compressed air. The vibration of the needles chips away rust, old paint, scale, and marine growth on metal surfaces. Think of it as “pangbaklas ng kalawang, pero industrial version.” Purpose: • Remove rust, corrosion, and scale from steel surfaces • Prepare metal before painting, welding, or coating • Clean areas where grinders and wire brushes can’t reach (corners, tight spots, edges) • Reduce manual scraping time and physical fatigue How to Use: 1. PPE First • Safety goggles / face shield • Ear protection (maingay ’yan) • Gloves • Mask (dust/rust particles) • Proper coverall 2. Check the Tool • Inspect air hose, connectors, and needles • Ensure air compressor pressure is within recommended range (usually 90 psi ± depending on tool) 3. Connect to Compressed Air • Attach hose firmly • Open the air valve gradually 4. Operate • Hold the tool with both hands • Press the needles gently against the surface — do not push too hard • Let the vibration do the work • Work in steady strokes 5. After Use • Shut off air supply • Clean and oil the needles to prevent rust • Store in dry location

Lathe Machine

LATHE MACHINE; THE MOTHER OF ALL MACHINES A lathe machine is a powerful tool in both industrial and maritime workshops. By rotating a workpiece against a cutting tool, it enables precise shaping, drilling, and finishing of materials. This makes it vital for manufacturing components such as shafts, propeller parts, and other cylindrical items that require high accuracy. How a Lathe Machine Works At its core, a lathe machine consists of a headstock, tailstock, bed, and carriage. The headstock houses the spindle and speed controls, delivering rotational motion to the workpiece. The tailstock provides support and can hold auxiliary tools like drills or reamers. The bed acts as a rigid base, ensuring that all other components remain aligned. Mounted on the bed, the carriage including the saddle, cross-slide, and tool post movably carries the cutting tool, while the lead screw and feed rod drive the tool’s motion for threading and feeding. Operations You Can Do on a Lathe Lathes are extremely versatile. Here are some of the most common operations: Turning: Reducing the diameter of a workpiece to form cylinders or tapered shapes. Facing: Creating flat surfaces on the ends of the piece. Parting: Cutting off a portion of the workpiece. Boring: Enlarging existing holes or providing a precise internal diameter. Thread Cutting: Cutting internal or external screw threads. Knurling: Forming patterned grips on handles or tool surfaces. Drilling: Using a drill held in the tailstock to bore holes with high accuracy.

WHAT IS ECDIS?

ECDIS stands fo ELECTRONIC CHART DISPLAY AND INFORMATION SYSTEM replaces traditional paper nautical charts with a digital interface that complies with International Maritime Organization (IMO) standards. It uses data from GPS, radar, AIS (Automatic Identification System), and other sensors to give the ship's crew a detailed and accurate picture of their surroundings and navigation route

Central Cooling System

Central Cooling System (CCS) on Ships The Central Cooling System (CCS) is the primary method used on modern vessels to maintain safe operating temperatures for engines and auxiliary machinery. Instead of relying on multiple separate cooling circuits, a CCS uses a single freshwater loop to cool major equipment. This freshwater absorbs heat from engines and machinery and then transfers that heat to seawater through a central cooler. By using freshwater internally and seawater externally, the system offers both efficiency and protection for vital components. Purpose of the Central Cooling System The CCS is designed to provide a stable and controlled cooling environment for the ship’s mechanical systems. Its main purposes include: •Preventing Overheating: Engines, compressors, generators, and pumps produce significant heat during operation. The CCS ensures they remain within safe temperature ranges. •Reducing Corrosion: Freshwater circulates inside machinery rather than corrosive seawater, greatly extending equipment lifespan. •Improving Efficiency: Consistent cooling improves fuel efficiency, power output, and overall engine performance •Simplifying Maintenance: A centralized system requires fewer individual coolers, making inspection and repairs easier and more cost-effective. •Environmental and Safety Protection: Proper cooling prevents machinery failures that could lead to pollution, downtime, or emergency situations. A Brief History of Marine Cooling Systems Early ships relied on direct seawater cooling, where seawater passed directly through engines. While simple, this system caused rapid corrosion, fouling, and frequent breakdowns. As engine outputs increased with advancements in marine propulsion, a more reliable and controlled method became necessary. By the mid- 20th century, ships shifted toward a jacket-water (freshwater) cooling system, where freshwater circulated around the engine block. However, many small coolers were still used for individual machinery, creating complexity. The modern Central Cooling System emerged as a solution: •One freshwater loop for all machinery •One central cooler to transfer heat to seawater •Better temperature control and lower maintenance Today, the CCS is standard on most commercial vessels due to its efficiency and durability.
