Parts of the Anchor System of a Ship

What is the Anchor System of a Ship? The anchor system is essential equipment that secures a ship in place at sea or in port. It consists of interconnected parts such as the anchor, chain, windlass, and locker, working together to prevent drifting, protect the vessel, and ensure safety during operations, emergencies, or harsh weather conditions. Parts of the Anchor System of a Ship 1. Anchor A heavy steel device that grips the seabed to hold the ship in position. It prevents drifting due to wind, waves, or current, ensuring stability and safety. 2. Chain Cable A strong, durable chain linking the anchor to the ship. Its weight and strength allow effective seabed penetration, withstand high tension, and resist corrosion in harsh marine conditions. 3. Windlass A powerful mechanical device used to heave up or let go the anchor chain. Operated hydraulically, electrically, or manually, it ensures safe, efficient anchoring operations and controlled chain movement. 4. Chain Stopper A securing device that locks the anchor chain when not in use. It relieves stress on the windlass, prevents chain slippage, and ensures safety during sailing or rough weather. 5. Anchor Lashing Strong securing arrangement that holds the anchor firmly in place while the ship is underway. It prevents unwanted movement caused by vibration, waves, or ship motion, protecting vessel structures. 6. Hawse Pipe A cylindrical pipe at the bow through which the anchor chain passes from deck to sea. It aligns and protects the chain, preventing friction damage and entanglement.

Safety Valves vs Relief Valves

Safety Valves vs Relief Valves: Understanding Their Roles in Marine Engineering Safety valves and relief valves are crucial pressure-control devices used throughout marine and industrial systems, but they are often misunderstood or used interchangeably. In reality, each valve serves a distinct purpose based on the type of fluid in the system and the level of protection required. Safety valves are primarily used in systems containing compressible fluids, such as steam, air, or gas. Their main purpose is to prevent dangerous overpressure conditions that can occur suddenly, especially in boilers and steam lines. When pressure reaches the set limit, a safety valve opens instantly, releasing a large amount of steam or gas in what is known as “pop action.” This rapid discharge prevents severe equipment damage, structural failure, and potential explosions, making safety valves one of the most critical safety components on board a vessel.

Types of Ship Anchor

What is anchor? An anchor is a heavy device, typically made of metal, that is used to connect a vessel to the bed of a body of water to prevent the vessel from drifting due to wind or current. Purpose ‣To Hold the Vessel in Place It secures the ship in a fixed location, especially when it is not at a dock or port. ‣To Prevent Drifting It stops the vessel from being carried away by wind, waves, or currents. ‣To Provide Safety in Emergencies In case of engine failure or rough weather, the anchor helps prevent the ship from drifting into danger. ‣To Assist in Positioning During Operations Useful for activities like dredging, diving, or repairs where stability is essential. 1. Fluke Anchor (Danforth) The Fluke anchor, also known as the Danforth anchor, is a lightweight, high-holding power anchor designed with two wide flat flukes that pivot on a shank. Purpose: It is ideal for anchoring in sandy or muddy bottoms, where its broad flukes can dig in deeply and hold firmly. Key Features: ‣Made of high-strength steel or aluminum ‣Lightweight and easy to handle ‣Excellent holding power relative to its weight ‣Commonly used on smaller vessels, yachts, and recreational boats 2. Plow Anchor (CQR) The Plow Anchor, commonly known as the CQR anchor (short for Coastal Quick Release), features a single plow-shaped fluke that pivots on a shank, resembling a farmer’s plow. Purpose: Designed to penetrate and bury itself in a variety of seabeds, it is widely used for general-purpose anchoring, especially in changing conditions Key Features: ‣Heavy-duty forged or cast steel construction ‣Hinged design allows it to adapt to shifting loads ‣Performs well in sand, mud, gravel, and some grassy bottoms ‣Often seen on cruising and commercial vessels 3. Bruce Anchor The Bruce anchor, also known as the Claw anchor, is a one-piece anchor with a claw-like shape designed to dig into the seabed and provide steady holding power. Purpose: Developed originally for offshore oil rigs, the Bruce anchor is now popular for small to medium recreational boats due to its reliable setting and holding capabilities. Key Features: ‣Made from forged or cast steel ‣One-piece construction with no moving parts ‣Performs well in sand, mud, and some rocky bottoms ‣Commonly used by cruising yachts and powerboats

JET CHISEL

A jet chisel (also called needle scaler) is a pneumatic tool made up of multiple thin steel rods (“needles”) that rapidly move back and forth when connected to compressed air. The vibration of the needles chips away rust, old paint, scale, and marine growth on metal surfaces. Think of it as “pangbaklas ng kalawang, pero industrial version.” Purpose: • Remove rust, corrosion, and scale from steel surfaces • Prepare metal before painting, welding, or coating • Clean areas where grinders and wire brushes can’t reach (corners, tight spots, edges) • Reduce manual scraping time and physical fatigue How to Use: 1. PPE First • Safety goggles / face shield • Ear protection (maingay ’yan) • Gloves • Mask (dust/rust particles) • Proper coverall 2. Check the Tool • Inspect air hose, connectors, and needles • Ensure air compressor pressure is within recommended range (usually 90 psi ± depending on tool) 3. Connect to Compressed Air • Attach hose firmly • Open the air valve gradually 4. Operate • Hold the tool with both hands • Press the needles gently against the surface — do not push too hard • Let the vibration do the work • Work in steady strokes 5. After Use • Shut off air supply • Clean and oil the needles to prevent rust • Store in dry location
